ROTOLIP®
Rotary lip seals for rotating shaft. Integrated body and sealing lip in Neuflon-ptfe compound. Available with or without auxiliary O-Ring.
An inox support ring can be implemented according with the working conditions, it is supplied as standard when the shaft exeeds 100 mm.
|
Food, pharma and chemical applications.
Wide range of chemical resistance.
Suitable for lubricated or dry running conditions.
|
 |
Rotoenerseal
spring energized rotary seal
single acting
medium pressure
moderate speed |
Criogenic applications
Food and pharma applications
Optional FDA approved silicone filling
Wide range of chemical resistance
|
 |
Rotoslipper
double acting composite rotary seal
high pressure
low speed |
High pressure rotary seals.
Slow rotating movements, fast translational movements, combined roto-translational movements.
Max Pressure 800 bar.
Temperature range -60 a + 150°C
|
 |
Rotowiper
single acting composite rotary seal
low pressure
low speed |
Closed groove
Very low torque
Protected wiping lip
Wide chemical resistance range
|
|
|
|
ROTOLIP®
Rotary lip seals for rotating shaft. Integrated body and sealing lip in Neuflon-ptfe compound. Available with or without auxiliary O-Ring.
The inox support ring can be implemented according with the working conditions, it is supplied as standard when the shaft exeeds 100 mm.
|
 |
|
 |
Rotolip® standard
Monodirectional rotary seal.
FDA applications
Available for any shaft from 6 to 350 mm
|
Operating conditions:
Temperature: -60 +250 °C
Speed: max 10m/sec if dry, up to 25m/sec with lubrication
Pressure: max 4 bar ( up to 10 bar with backup )
Versions R01 and R011 without support ring: shaft 100mm max.
Runout max 0,15mm
|
|
 |
Rotolip® reinforced lip
Monodirectional rotary seal.
FDA applications.
Available for any shaft from 6 to 350 mm
|
Operating conditions:
Temperature: -60 +250 °C
Speed: max 5m/sec if dry, up to 15m/sec with lubrication
Pressure: max. 4 bar ( up to 10 bar with backup )
Versions R05 and R055 without support ring: shaft 100mm max.
Runout max 0,15mm
|
|
 |
Rotolip® garter
Monodirectional rotary seal.
FDA applications
Available for any shaft from 6 to 350 mm
|
Operating conditions:
Temperature: -60 +250 °C
Speed: max 5m/sec if dry, up to 10 m/sec with lubrication
Pressure: max. 4 bar ( up to 10 bar with backup )
Versions R07 e R077 without support ring: shaft 100mm max.
Runout 0,30 mm max.
|
|
 |
Rotolip® double lip
Monodirectional rotary seal.
Allows creating a reserve of lubricant between the sealing lips.
Available for any shaft from 20 to 350 mm
|
Operating conditions:
Temperature: -60 a +250 °C
Speed: max. 5 m/sec if dry, up to 15m/sec with lubrication
Pressure max. 4 bar
Runout 0,15mm max.
|
|
|
Rotolip® with opposite lips
Bidirectional rotary seal.
Available for any shaft from 20 to 350 mm
|
Operating conditions:
Temperature: -60 a +250°C
Speed: max. 5 m/sec if dry, up to 15 m/sec with lubrication
Pressure max. 2 bar
Dimensions on request
|
|
